SMS SubMonitor Pump Starter
Starters
SMS SubMonitor Pump Starter
Equipped with the Franklin Electric SubMonitor Connect overload relay, the SMS provides ideal motor protection for Franklin Electric submersible motors.
![FE_Select_Logo_Tagline_BLK.psd](https://embed.widencdn.net/img/fele/qnfryelgui/750x257px@1x/FE_Select_Logo_Tagline_BLK.jpg?q=80&x.template=y&crop=false&k=c)
Available on FE Select
Size. Configure. Quote. Input your performance requirements or specs, and our industry-leading online tool will help you find the right Franklin Electric product for the job.
Overview
Electronic Overload Motor Protection
- Wide range, adjustable, class 5-30 electronic overload
- Dry pump detection protects your pump and motor from adverse conditions and allows for time-based automatic restart with well recovery mode
- Industry-leading motor protection for the following conditions:
- Over/under power (dry-run)
- Over/under voltage protection
- Voltage phase loss
- Voltage
- Current phase unbalance
- Locked rotor
- Cycle fault
- Ground Fault
- Easy access to input and output terminals
- 32-character, backlit, NEMA 4x, wash-down rated screen mounted on front of panel allowing for safe viewing of conditions while motor is running
- Motor insulation check
Real-time & Date-stamped Fault Logging
- Unit ships with a pre-programmed real time clock with a 10-year battery backup
- Contains separate fault, configuration change, and start logs. Independent logs allow user to see last fault even if it occurred years ago
- Fault log tracks 150 faults with date and time stamp accurate down to the second:
- Allows users to diagnose power problems and prove them to your power provider
- Unit will give users a ‘snapshot’ of conditions at the time of fault, such as line to line voltage and current, alarms present, and I/0 status
- Format of time stamping example: 7/7/16 10:15:24
Application-based Setup
- SubMonitor Connect is an advanced, comprehensive, 3 phase motor protection relay that allows users to dial in protection and automation with extreme accuracy and parameter depth. However, SubMonitor Connect also has a streamlined Basic Setup Wizard to allows user to get up and running quickly
- 9 simple steps to program unit
- Users select between Submersible, Surface, or Custom and SubMonitor prepopulates protection parameters accordingly
- Confirm basic motor info, key protection info, time to get started
Automation Ready - Advanced Pump Control
- 12-240 VAC/VDC wet input for remote start/stop
- Dry contacts for auto run/shutdown or high float/low float
- Modbus RTU communication
- Automatic fault reset and on and off delay settings
- Automatic fault reset and on and off delay settings
Heavy-duy Industrial-grade Construction
- Outdoor rated, gasketed, powder coated, NEMA 3R enclosure designed in house by Franklin Electric to optimize layout and functionality
- UL 489 circuit breaker disconnect for branch and short circuit protection
- No fuses required saving time and money
- Lockable handle
Order Information
UL Type 3R - 200-600VAC
Item | Maximum Current | Branch Protection Included |
---|---|---|
SMS3B-3A015S1 | 8 A | Yes |
SMS3B-3A020S1 | 11 A | Yes |
SMS3C-3A030S1 | 17 A | Yes |
SMS3D-3A040S1 | 22 A | Yes |
SMS3E-3A050S1 | 28 A | Yes |
SMS3E-3A060S1 | 34 A | Yes |
SMS3F-3A080S1 | 45 A | Yes |
SMS3F-3A100S1 | 52 A | Yes |
SMS3G-3A100S1 | 57 A | Yes |
SMS3G-3A125S1 | 71 A | Yes |
SMS3H-3A150S1 | 85 A | Yes |
SMS3I-3A200S1 | 114 A | Yes |
SMS3I-3A250S1 | 130 A | Yes |
SMS3K-3A300S1 | 171 A | Yes |
SMS3K-3A400S1 | 228 A | Yes |
SMS3L-3A500S1 | 285 A | Yes |
SMS3L-3A600S1 | 342 A | Yes |
SMS3L-3A800S1 | 361 A | Yes |
