Integrated electronic motor and pump protection

• Enhanced Class 10 electronic overload protection
• Specifically designed for submersible motors
• Built-in 1.15 service factor compensation
• Underload (dry-run protection)
• Current phase unbalance protection
• Cycle fault protection
• Locked rotor and stall protection

Multi-voltage operating range with automation I/O

• Accepts 200-600 VAC directly, true plug and play
• Includes a dry contact auto-run input and fault relay output

Industrial grade construction

• Door mounted heavy-duty HOA switch
• Housed in an outdoor rated, gasketed, NEMA 3R enclosure
• NEMA/IEC rated magnetic contactors feature 2.5 million electrical cycles at full rated current

Optional circuit breaker disconnect (Service Entrance rated)

• UL 489 circuit breaker provides branch and short circuit protection
• No fuses required – saves time and money
• Lockable handle for safety

Revolutionary Motor Protection

• Aware: SMARTSTART™ protects your system from adverse dry-run conditions with built-in underload protection standard.
• Watchful: SMARTSTART™ detects harmful extended starting conditions with maximum time to start. Monitors motor in-rush current conditions and trips if the motor doesn’t start within 10 seconds (class 10 overload) regardless of FLA setting.
• Active: Active current monitoring provides superior protection against locked rotor and stall conditions, tripping faster than a standard inverse trip curve, regardless of the FLA setting.
